23248CC/C3W33 Spherical roller bearing
Product Details:
| Model Number: |
23248CC/C3W33 |
Payment & Shipping Terms:
| Minimum Order Quantity: |
1 |
Contact Now
Detailed Product Description
Spherical roller bearings
Spherical roller bearings have two rows of symmetrical rollers, a common sphered outer ring raceway and two inner ring raceways inclined at an angle to the bearing axis (
fig. 1). The centre point of the sphere in the outer ring raceway is at the bearing axis.
Bearing features
- Accommodate misalignment
Spherical roller bearings are self-aligning like self-aligning ball bearings or CARB bearings ( fig. 2 ).
- High load carrying capacity
Spherical roller bearings are designed to accommodate both heavy radial loads and axial loads in both directions.
- Long service life
The rollers are manufactured to such tight dimensional and geometrical tolerances that they are practically identical in a roller set. The symmetrical rollers self-adjust ( fig. 3 ), providing optimal load distribution along the roller length and together with the special profile prevent stress peaks at the roller ends ( fig. 4 ).
- Low friction
Self-guiding rollers keep friction and frictional heat at low levels ( fig. 5 ). A floating guide ring guides unloaded rollers so that they enter the load zone in the optimal position.
- Robust
All spherical roller bearings contain strong window- or prong-type cages.
