Product Manufacturer Long Using Life Good Performance NTA-3648 Thrust Caged Needle Roller Bearing 2-1/4x3x5/64 TC3648 NTA3648
Product Details:
| Place of Origin: |
China |
| Brand Name: |
STAROCK |
| Model Number: |
NTA3648 |
Payment & Shipping Terms:
| Minimum Order Quantity: |
1 |
| Delivery Time: |
3-7 work days |
| Payment Terms: |
T/T, Western Union, L/C |
Contact Now
Detailed Product Description
Key Features
NTA3648 is a Thrust Caged Needle Roller Bearing designed for use with TRB-Series thrust washer and cage assemblies in applications where adjacent components cannot serve as raceways. The thrust washer serves as a raceway surface for the thrust assembly’s rolling elements and can be used as a shaft washer (bore-piloting washer) fixed on the shaft or a housing washer (outer diameter-piloting washer) fixed in the housing. Both sides of the washer can be used as raceways and are flush ground for higher speeds and greater running accuracy than unground raceways. The washer is made of low alloy, through-hardened chromium steel for durability, heat tolerance, and resistance to deformity under heavy loads. This thrust washer is for use in various applications including machine tool drive shafts, automotive steering gears and clutches, rotary tables, outboard motor propellers, and household appliances.
- Inner Diameter:
- 2-1/4"
- Outer Diameter:
- 3"
- Width:
- 5/64"
- Material:
- Chrome Steel SAE-52100
- Lubrication:
- Light Oil
- Static Load:
- 7,193 lbf
- Dynamic Load:
- 1,252 lbf
- Speed Limit:
- 5,600 RPM
- Country of Origin:
- China
- Interchange Numbers:
- TC3648, WGB2078547, NTA-3648, TRB-3648, 35TY02, 94517, 31171507
