Product Details:

Place of Origin: German
Brand Name: FAG
Model Number: подшипники FAG

Payment & Shipping Terms:

Minimum Order Quantity: 10 pcs
Price: 1
Packaging Details: CARTON
Delivery Time: 4-7days
Payment Terms: L/C,D/P,T/T,Western Union,paypal
Contact Now
Detailed Product Description



FAG Z-531152.04.DRGL
Description:
d(mm):160
D(mm):420
C(mm):118
B1(mm):138
B2(mm):148
quality(kg):93
FAG Z-531152.04.DRGL triple ring bearings for the paper industry In order to achieve a constant distribution of pressure and thus uniform paper thickness over the entire web width, so-called deflection compensating rolls are used in presses and calenders in paper machinery.In these rolls, the roll shell rotates about the stationary roll axis. The roll shell is supported in relation to the axis by means of various hydraulic systems that influence the geometry of the roll shell and match this to the shell profile of the opposing roll. Such rolls can be driven or non-driven. In the case of driven rolls, triple ring bearings are frequently used. When triple ring bearings are fitted, the stationary axis – the so-called crosshead– is supported in the bearing inner ring. The rotating middle ring connects the drive to the roll shell.
